Tr4 Metal Roof Panel Roll Forming MachinePeople use Roofing Sheet Machine, Such as Tr4 Metal Roof Panel Roll Forming Machine, Trapezoidal Sheet Roll Forming Machine to produce metal sheet for industrial, commercial and residential roof cladding. Although there are numerous profiles of roofing sheet, the process of forming is the same. Coils (GI coils, PPGI coils, GL coils, PPGL coils, etc) go through decoiling, roll forming, cutting and then come out the desired roof products .
| Coil Required |
Material |
PPGI GI AL |
| Width |
914/925/1000/1200/1220/1250mm |
| Thickness |
0.3-0.7mm as custom order |
| Power Required |
Power |
380V 50Hz 3 Phase, 220V, 415V available |
| Main Motor |
5.5KW Siemens Brand |
| Cutting Motor |
4KW Siemens Brand |
| Machine |
Support Frame |
40H Steel |
| Forming Stations |
18 Rows as profile require |
| Structure |
18-20mm |
| Shaft |
75mm Solid shaft |
| Roller |
45# Steel with hear treatment |
| Chain |
1.2inch |
| Bearings |
Standard as custom order |
| Speed |
15-3-m/min |
| Electric Components |
Delta and Siemens brand |
| Size |
7.5*1.3*1.6M |
| Weight |
4T |
Application of
Roof Panel Roll Forming Machine
Besides of Roof Tile Forming Machine, We also have IBR sheet forming machine, corrugated sheet forming machine, Ridge cap forming machine , Floor deck forming machine etc . Welcome to call us for more information .
